Besides offering the BIG.NINE in a full carbon version, we also have BIG.NINE LITE and BIG.NINE/ SEVEN TFS aluminium frames in our range. While the LITE features the same race-proven geometry as the carbon models, the TFS bikes offer a more relaxed geometry, through a shorter top tube and a higher head tube, resulting in a more upright riding position and enhanced trail visibility. The TFS frames feature internal cable routing (except the BIG.NINE/BIG.SEVEN 15), smooth welding, tapered head tube, inboard disc mounts, and mounts for fenders, rear rack and kickstand.
THIS IS WHAT WE DO
Our classic hardtails are the backbone of our range and showcase the enormous wealth of experience and knowledge we were able to gain in 48 years of bike production and manufacturing. The BIG.NINE and BIG.SEVEN range symbolises the symbiosis between modern frame technology, attention to detail and craftsmanship 'Made in Taiwan'.
Availability Everything found in the catalog is available in our stores and warehouses | |||||
---|---|---|---|---|---|
Color: | Frame size: | Price: | Location: | Barcode: | |
Brown / Blue | 17" / M | 879.00 EUR | K28 V L N |
6110894923003
|
Add to cart |
Grey / Black | 17" / M | 879.00 EUR | K28 V L N |
6110894871007
|
Add to cart |
Brown / Blue | 18.5" / L | 879.00 EUR | K28 L N |
6110894934009
|
Add to cart |
Brown / Blue | 20" / XL | 879.00 EUR | K28 V L N |
6110894945005
|
Add to cart |
Grey / Black | 20" / XL | 879.00 EUR | K28 V L N |
6110894893009
|
Add to cart |
Brown / Blue | 22" / XXL | 879.00 EUR | N |
6110894956001
|
Add to cart |
Grey / Black | 22" / XXL | 879.00 EUR | K28 V L N |
6110894901001
|
Add to cart |
Specification | |
---|---|
Stem | MERIDA COMP CC Aluminium 31.8mm diameter 7° stem angle S-70 mm, M-80 mm, L-90 mm, XL-100 mm, XXL-110 mm |
Permitted max. weight | 135 kg |
Suspension | Front suspension |
Cassette | Shimano HG200 11-36 teeth 9 speed |
Tyres | Maxxis Ikon 29x2.2" wire |
Spokes | Black stainless |
Shift levers | Shimano Altus |
Seatpost | Shimano Altus |
Seat clamp | MERIDA COMP QR |
Saddle | MERIDA COMP CC |
Rims | MERIDA COMP CC 20mm inner width Aluminium |
Pedals | VP VPE-891 |
Rear hub | Shimano TX505 135x9mm width rear hub 32 spoke holes Centerlock |
Front hub | Shimano TX505 100x9mm width front hub 32 spoke holes Centerlock |
Headset | MERIDA M2345 |
Brakes | Hydraulic disc brakes |
Handlebars | MERIDA EXPERT CC Aluminium 720mm width 10mm rise |
Grips | MERIDA COMP EC |
Rear derailleurs | Shimano Alivio Shadow SGS |
Front derailleurs | Shimano M2020-TS |
Crankset | Shimano MT101-2 36-22 teeth 170 mm-S, 175 mm-M up |
Chain | KMC M99 |
Rear brakes | Tektro M275 2 piston Shimano RT10 160mm rotor |
Front brakes | Tektro M275 2 piston Shimano RT10 180mm rotor |
Bottom bracket | FSA TH-7420ST |
Fork | Suntour XCR32 LOR Air 100mm suspension travel Lockout 46mm fork offset 29x2.25" max. wheelsize |
Gears | 9 X 2 |
Frame | BIG.NINE TFS III Aluminum 29x2.25" max. wheelsize 135x9mm axle standard BSA bottom bracket standard Smooth welding |
Wheel size | 29 " |
Frame material | Aluminium |
Weight | 13.35 kg |
Catalog numbers | 6110894923, 6110894871, 6110894934, 6110894945, 6110894893, 6110894956, 6110894901 |
