| Availability Everything found in the catalog is available in our stores and warehouses | |||||
|---|---|---|---|---|---|
| Color: | Frame size: | Price: | Location: | Barcode: | |
| Blue / Yellow | 15" / S | 649.00 EUR | L N |
6110887607002
|
Add to cart |
| Blue / Yellow | 17" / M | 649.00 EUR | K28 |
6110887618008
|
Add to cart |
| Specification | |
|---|---|
| Stem | MERIDA CC Aluminium 31.8mm diameter 6° stem angle 70 mm-XS/S, 80 mm-M, 90 mm-L |
| Permitted max. weight | 135 kg |
| Suspension | Front suspension |
| Cassette | Sunrace CSM668 11-32 teeth 8 speed |
| Tyres | MERIDA K1080 27.5x2.2" wire |
| Spokes | Black steel |
| Shift levers | Shimano ST-EF505 |
| Seatpost | MERIDA CC Aluminium 30.9mm diameter 15mm setback |
| Seat clamp | MERIDA COMP QR |
| Saddle | MERIDA Sport comfort |
| Rims | MERIDA CC 17mm inner width Aluminium |
| Pedals | VP VPE-891 |
| Rear hub | Shimano TX505 135x9mm width rear hub 32 spoke holes Centerlock |
| Front hub | Shimano TX505 100x9mm width front hub 32 spoke holes Centerlock |
| Headset | MERIDA M2345 |
| Brakes | Hydraulic disc brakes |
| Handlebars | MERIDA CC Aluminium 690mm width 15mm rise |
| Grips | MERIDA EC |
| Rear derailleurs | Shimano RD-M360 |
| Front derailleurs | Shimano FD-TY700 |
| Crankset | Shimano TY301 42-34-24 teeth 170 mm-XS/S, 175 mm-M/L |
| Chain | Sunrace M84 |
| Rear brakes | Shimano ST-EF505 BR-MT200 brake caliper Shimano RT10 160 mm rotor |
| Front brakes | Shimano ST-EF505 BR-MT200 brake caliper Shimano RT10 160 mm rotor |
| Bottom bracket | FSA TH-7420ST-W, Cartridge Bearing |
| Fork | Suntour XCT30 HLO Coil 100mm suspension travel Lockout 27.5x2.25" max. wheelsize |
| Gears | 8 x 3 |
| Frame | BIG.SEVEN TFS III Aluminium 27.5x2.25" max. wheelsize 135x9mm axle standard BSA bottom bracket standard |
| Wheel size | 27.5 " |
| Frame material | Aluminium |
| Weight | 14.5 kg |
| Catalog numbers | 6110887607, 6110887618 |
| Loan calculator | |
|---|---|
