BUILT-IN VERSATILITY
While clearly a trail loving long-travel hardtail, our new BIG.TRAIL also offers built-in versatility through hidden rack, fender and kick stand mounts in case you like to turn the BIG.TRAIL into a ‘SUV’ commuter.
DOUBLE BOTTLE
Ability to fit two water bottles into the frame without making the bottles difficult to reach. Perfect for long marathon races and extended trail sessions.
TYRE CLEARANCE BIG.TRAIL
Our BIG.TRAIL rolls on 29er wheels and has tyre clearance for up go 2.5" trail tyres. The combination of 29er wheels and 2.5" tyres offer plenty or corner and climbing grip, while the big tyre volume and the 29er 'rolling over ability' give our trail hardtail extra comfort and stability.
TRAIL MOUNT
The new 'Trail Mount' is positioned underneath the top tube/seat tube junction and these ingenious fixing points makes fitting an additional tool or a pump a breeze. The 'Trail Mount' offers a real advantage if you prefer to keep the weight off your back or if you are heading out for an extra-long outing where you might need to carry additional gear.
INTERNAL CABLE ROUTING
We feature internal cable routing on all models. Cables are routed through the frame, entering and exiting through smooth sockets. Only a clever system for our internal guiding and fixing guarantees reliable and rattle free routing, whilst the cables are protected from moisture and dirt and gives the bike a cleaner look.
MODERN TRAIL GEOMETRY
A long reach, paired with a slack 65.5° head angle and a steep seat angle make our BIG.TRAIL a solid descender even when the trail is littered with roots and rocks, while maintaining impressive climbing abilities, due to the central seating position over the bottom bracket. The extra short seat tube and low stand over hight help to create lots of space to manoeuvre the bike when the trail gets demanding but also allow for long travel dropper posts.
BOOST TECHNOLOGY
Most models offer Boost technology at the front and rear. The shallower axle standard of 110 mm (front) and 148 mm (rear) allows for a wider spoke angle, resulting in a stiffer and stronger wheel, hugely beneficial on these bikes given the impacts they endure. The BIG.TRAIL 200 has 100 mm fork spacing.
Specification | |
---|---|
Headset | MERIDA M4455 |
Permitted max. weight | 135 kg kg |
Suspension | Front suspension |
Cassette | Shimano Deore M5100 11-51 teeth 11 speed |
Tyres | Maxxis Dissector 29x2.4" fold TR EXO Dual |
Spokes | Black stainless |
Shift levers | Shimano SL-MT500-L / Shimano Deore M5100 |
Seatpost | MERIDA COMP TR 30.9mm diameter 0mm setback S: 125mm travel seatpost - M/L/XL: 150mm travel seatpost |
Seat clamp | MERIDA EXPERT |
Saddle | MERIDA COMP CC |
Rims | MERIDA COMP TR 29mm inner width material: aluminium Tubeless ready (tubeless tape and valves not included) |
Pedals | VP VPE-891 |
Rear hub | Shimano MT400-B 148x12mm width rear hub 32 spoke holes Centerlock MERIDA COMP TR axle including removable lever, 6 allen key |
Front hub | Shimano MT400-B 110x15mm width front hub 32 spoke holes Centerlock MERIDA COMP TR axle including removable lever, 6 allen key |
Brakes | Hydraulic disc brakes |
Stem | MERIDA EXPERT TR Aluminium 35mm diameter 0° stem angle 50 mm all sizes |
Handlebars | MERIDA EXPERT TR Aluminium 780mm width 20mm rise |
Grips | MERIDA COMP EC |
Rear derailleurs | Shimano Deore M5100 Shadow+ SGS |
Crankset | Mr. Control CH-CM1 Shimano Deore M5100 32 teeth 170 mm-S, 175 mm-M up |
Chain | KMC X11 GRY/GRY |
Rear brakes | Tektro M275 2 piston Shimano RT10 180mm rotor |
Front brakes | Tektro M275 2 piston Shimano RT10 180mm rotor |
Fork | Rock Shox Recon Silver RL 140mm suspension travel Tapered 42mm fork offset 29x2.8" max. wheelsize |
Gears | 11 x 1 |
Frame | BIG.TRAIL TFS Aluminium 29x2.5" max. wheelsize 148x12mm axle standard BSA bottom bracket standard |
Wheel size | 29 " |
Frame material | Aluminium |
