Lubricant oil Black Diamond Chain Lube 30g

SUPREME PERFORMANCE IN DRY AND WET
ONE OF THE FASTEST EVER
CHAIN LUBES IN INDEPENDENT LABORATORY TESTING.

Wheel Energy laboratories is one of the few completely independent chain lube efficiency testing labs in the world. They were also an important partner in the extensive development process of Rex Black Diamond chain lube.

In a 300 km dynamometer test under 175 W magnetic resistance, Rex Black Diamond gave the best overall result, leaving competing high-end chain lubricants behind. The test protocol was designed by Wheel Energy, with no instructions or other input from Rex. In addition to lab tests, Black Diamond has proven its performance in Tour de France 2019 (1 stage win).


TEST RESULTS
THREE HUNDRED KILOMETER RACE SIMULATION AT 40 KM / H


x-axis: 21 measuring points, 15km between measurements, along 300 km test @ 40 km/h (7,5 hours)
y-axis: Power loss compared to lowest value as measured by Wheel Energy dynamometer

Test protocol designed by Wheel Energy laboratories
All chains prepared by Wheel Energy
175W magnetic resistance, duration 300 km
Bicycle drive train with a spring loaded single speed chain tensioner
Not a so-called FTT full tension test
Dura-Ace chain and chainrings
Average of 20 measurements, high and low peak values removed
30 minute warmup prior measuring
Ambient temperature 25°C, humidity 32%
Chain ultrasonically cleaned before lubing
Ufo Drip applied as per manufacturers’ recommendation
Chain rotating the same way in every measurement
BLACK DIAMOND
ULTRASONICALLY TREATED IN REX R&D LAB

The secret of our new lube are the Black Diamond particles that are mixed into the lube in a time-consuming ultrasonication process at our factory’s Racing Service lab.

The Black Diamond particles significantly improve the properties of the lube: Lower friction, lower wear and increased rain resistance.

In continuous metal-to-metal contact that occurs in drivetrain while riding, the particles form an ultra-thin and hard layer that minimizes friction and wear, and is also waterproof.

Best lubrication performance and longevity will be achieved after 3–4 applications, when the lube has completely penetrated into the chain.

RAINPROOF
NEXT LEVEL COMBINATION OF DRY AND WET WEATHER PERFORMANCE

Previously, seeking for the lowest possible friction in a chain lube has meant sacrificing all-weather performance. So-called “wet” lubes have traditionally been very energy-stealing.

Rex Black Diamond combines test-winning friction levels with strong weather resistance in a previously unseen way. Black Diamond has been tested in demanding race conditions by our elite athlete team. The true king of chain lubes!


N-KINETIC™ WAX
FEATURING THE LATEST RACE SKI WAX TECHNOLOGY

We have upgraded the wax blend used in Black Diamond lube to the same Rex N-kinetic™ technology that we is used in our best cross-country ski waxes. The slightly lower viscosity results into lower friction and better lube penetration into the chain. Rex is well known for its world cup level fluorinated ski waxes and is an expert in paraffin wax-based applications with six decades’ worth of experience.



WAX BASED
SOLVENT-FREE, NON-VAPORIZING, UNDILUTED

Adding solvent or water to a chain lube is generally thought to be a great way to reduce manufacturing cost and giving the manufacturer a better margin. At Rex, we think otherwise. Every drop you apply on the chain is 100% lubricant and not something that will evaporate into the air. Unlike with most chain lubes, there is no need to wait until the solvent evaporates before you can ride your bike.



UP TO 30 WAXINGS FROM A SINGLE BOTTLE
UP TO 500 KM WITH ONE WAXING
DETAILED INSTRUCTIONS
FOR ACHIEVING THE BEST LUBRICATION PERFORMANCE

Clean and degrease the chain thoroughly using a detergent like Rex Chain Cleaner, a chain cleaning device, or brush. Rinse well with water and let dry completely. Shake the bottle well and begin applying lube 1 drop per roller while pedaling backward.Use fingers to smoothen out and work the lube into rollers while back-pedaling at least 3-4 revolutions. Repeat applying 1 drop per roller, using the same method as above. Lightly wipe off excess lube from the surface to avoid excess dirt build-up.
